Y71 200T BMC Compression Molding Press Oil Hydraulic Drive PLC Control

Brand Name : XINKE

Certification : CE, ISO9001:2000

Place of Origin : China

MOQ : 1 Unit

Price : USD 10000-1000000 Per Unit

Payment Terms : L/C, T/T

Supply Ability : 10 Units Per Months

Delivery Time : 90-180 Working Days

Packaging Details : Wooden case, waterproof cover

Frame : Four Columns

Drive : Oil Hydraulic

Control : PLC

Application : SMC, BMC Molding

Contact Now

Y71 200T Servo Hydraulic Press for BMC

Features:

  1. Finite element analyzed straight sided frame or four columns frame
  2. Latest closed-loop proportional control technology, digital display, slider position, working force, and working speed can be preset.
  3. Frequency conversion technology

Application:

Suitable for the thermal molding of various kinds of plastic materials. e.g. SMC, BMC, DMC. GMTLFT-D in following industries:

  1. Aviation
  2. Traffic
  3. Shipbuilding
  4. Automotive
  5. Architecture
  6. Petrochemical
  7. Energy

Accessories for option:

Moveable worktable

Ejection device

Knockout core

Painting

Vacuum system

Heating system

Light curtain safety device

Technical Data:

Item Unit Y71-200
Nominal force kN 2000
Pre-pressing force kN 630
Force of opening mould kN 4000
Force of ejection kN 400
Size of worktable L.R. mm 930
F.B. mm 900
T-slot 　 28
The opening daylight mm 1120
Stroke of slider t 710
Ejection stroke mm/s 200
Pressure of medium Mpa 25
Descend speed mm 120
Pre-pressing speed mm/s 5/20
Working speed mm/s 2/7
Speed of opening mould mm/s 5/30
Stroke of slider mm/s 100
Slow ejection speed mm/s 5/30
Quick ejection speed mm/s 80
Frame type 　 Four-Column
